TAP100 Tread & Tyre Pressure Testing Tool

Overview

The first integrated hand held Tread Depth and Pressure tool with colour display for cars, vans and light usage commercial vehicles. Easy-to-use colour coded graphics with Bluetooth communications to back office systems.

The TAP (Tread & Pressure) Reader is designed to give fast accurate results. It can eliminate the paperwork involved in collecting data and reporting the results to the customer. Using a colour coded warning system the tool shows when tyres are legal and when replacement is recommended. The highly accurate tool enables the tyre shop to advise the customer how long they can keep running their tyres before replacement is needed, thereby maximising tyre life and offering real value to the customer.

The results of the tread and pressure test can be uploaded via Bluetooth to a PC or tablet so that the colour coded warnings can be displayed for the customer thereby reassuring them of their legitimacy. This leads to increased tyre and parts sales, and customer retention.

TAP100 Features

  • 15mm replaceable steel pin with profiled end
  • High resolution, sunlight readable, 1.6” colour graphics display 240 x 240 pixels
  • Simple, intuitive, menu-driven software
  • Rugged ABS/Polycarbonate enclosure resistant to automotive fluids
  • Rated IP54 for water and dust ingress
  • Quick release lightweight pressure hose
  • Built in electronic pressure gauge
  • Rechargeable Lithium battery – wireless charging
MOT Approved

Technical Specification

  • 15mm steel depth pin with profiled end to meet regulations
  • Tread depth and pressure in one tool can capture all four wheels in under one minute
  • Maximum tread depth 12mm
  • 0.01mm accuracy version for UK MOT testing – EINYA19863-0716026
  • Pressure range 0-10bar (0-150PSI)
  • Pressure accuracy +/-0.07bar (+-1PSI)
  • Bluetooth for wireless data transfer
  • Wireless charging
  • Operating temperature 0 to 40°C
TAP100 Tread & Tyre Pressure Testing Tool
  • Built in lamp for illuminating tyre surface
  • Silicone rubber boot for added protection
  • No need to connect to another tool, Bluetooth communications - no cables
  • Colour screen for displaying legal and recommended replacement status
  • Red-amber-green intuitive user interface
  • Works with TPMS Desktop offering data management, TPMS information & software updates
  • Lamp highlights tread wear pattern & damage
  • Quick release lightweight pressure hose
  • High resolution colour display with sunlight readable
