TPMS Desktop Quickstart

Steps A & B - Download the TPMS desktop and configure settings

Link required: https://tools.bartecautoid.com/TPMSDESKTOP/publish.htm

1. User has to press the ‘Install’ button - Software is downloaded

2. Double click on the downloaded executable - Software is being installed and run(Shortcut installed on desktop)

3. User has to click on "Settings" - System settings menu appears

TPMS Desktop Settings

4. User has to make selections in:

  • Measurement Units
  • Languages
  • Click on "Register tool"
  • TPMS Desktop Settings

    Step C - Register user account

    Link required: https://tools.bartecautoid.com/login.aspx

    The user has to click on either ‘Register’ (red banner) or ‘click here to register’

    TPMS Desktop Settings

    5. This then takes the user to: https://tools.bartecautoid.com/login.aspx
    where they have to complete his details and click on a ‘Register’ button.

    They will receive a ‘Registration confirmation email’ with a link that they have to click on so that their email address is confirmed as a valid one.
    A click on that link takes you here:

    RDKS Desktop Settings

    https://tools.bartecautoid.com/Registration-Email-Awaiting-Confirmation.aspx

    6. The user can then log in with their user name and password and is taken to the ‘Tools’ tab.

    TPMS Desktop Settings

    7. On this tool tab the user has to click on ‘Register a new tool’.

    This takes the user to: https://tools.bartecautoid.com/RegisterTool.aspx

    TPMS Desktop Settings

    8. The user enters the ‘Serial Number’ and ‘Purchase date’ and clicks on the ‘Register’ button.

    RDKS Desktop Settings

    This is the end of this stage.

    The user now has to connect the USB lead from the Tech300 kit with:

    • the tool with the mini-USB connector
    • the PC with the other end of the cable, the USB connecter

    After a few seconds the PC will recognise the SD card in the tool as an external drive.

    Step D - Press the Update Tab on TPMS Desktop

    If the application is not currently running, start the TPMS Desktop, using the Short-Cut on the PC’s desktop.

    Press the ‘Update’ tab.

    TPMS Desktop Settings

    The ‘Tool management’ screen appears, displaying the Tech300 which is connected to the PC with the USB lead.

    If the Tool is not displayed, proceed with ‘Step E – Press Refresh’ below

    TPMS Desktop Settings

    Step E - Press "Refresh"

    Press Refresh

    TPMS Desktop Settings

    Then disconnect the tool from the PC and turn the tool off.

    Step F - Enter update mode on the tool

    The easiest way for the user to do this is by pressing both the ‘Enter’ + ‘On/Off’ keys simultaneously.

    The tool turns on and this is displayed on screen:

    When you press it, you see:

    TPMS Desktop Settings

    Then reconnect the tool with the PC.

    Step G - Press "Update" and follow on screen prompts

    TPMS Desktop Settings

    The ‘Current version’ of software (57.0) on this tool is older than the one that is currently available, ‘Latest version’, (58.2).

    In the ‘Connected Tools’ section the ‘Update’ button is dark grey, signifying it is active.

    When you press it, you see:

    RDKS Desktop Settings

    Press 'Update Tool.'

    RDKS Desktop Settings

    When the update is complete, you get this:

    RDKS Desktop Settings

    You can now unplug the tool.
